Dual Monitor 4K 10.2Gbps HDMI USB KVM Extender

Dual Monitor 4K 10.2Gbps HDMI USB KVM Extender Over IP via Two CATx Cables with Video Wall Support

Model No : ST-IPUSB4K-VWDH

Weight In KG :1.41140

Weight In LB :3.1116



Request for Price
  • Description
  • Sepcification
  • Download
  • Buy

INTRODUCTION

      • The Dual Monitor 4K 10.2Gbps HDMI USB KVM Over IP Extender provides remote KVM (USB keyboard, USB mouse, and two 4Kx2K 30Hz HDMI monitors) access to a dual-head USB computer up to 492 feet (150 meters) via two CAT6/6a/7 cables.
      • Each KVM extender consists of the ST-IPUSB4K-L-VWDH local unit that connects to a dual-head computer and also supplies video to two local monitors, and the ST-IPUSB4K-R-VWDH remote unit that connects to two HDMI monitors, 3.5mm stereo audio speakers and microphone, and up to four USB devices (keyboard, mouse, flash drive, HDD, or touchscreen display).
      • The local and remote units can be connected together for a Point-to-Point connection via CATx cable, or a Point-to-Many or Many-to-Many connection via a managed Gigabit network switch.
      • Supports Ultra-HD 4Kx2K resolutions to 3840x2160 (30Hz), 2K resolution 2048x1080, HDTV resolutions to 1080p, and up to 1920x1200 (WUXGA).
      • Extend 4Kx2K up to 492 feet in a Point-to-Point connection.
      • Extend 4Kx2K up to 984 feet in a Point-to-Point, Point-to-Many, or Many-to-Many connection via a managed Gigabit network switch.
      • The max length between most switches and the local/remote unit is 492 feet.
      • The switch itself will determine the maximum distance.

HDMI features supported:

      • HDMI 1.4
      • x.v.Color, sYCC601 color, Adobe RGB Color and Adobe YCC601 color
      • Dolby TrueHD, LPCM 7.1, DTS-HD Master Audio, Dolby Digital, and DTS
      • Bandwidth up to 340 MHz (10.2 Gbps)
      • Lip Sync
      • HDCP 1.4 compliant.
      • USB ports for keyboard, mouse, flash drive, HDD or touchscreen display.
      • Two USB 2.0 and two USB 1.1 connectors.
      • Keyboard and mouse are hot-pluggable.
      • Supports video wall installations from 1x2 to 4x4 screens.
      • Displays can be rotated 180 and 270°.
      • Plug-and-Play installation allows receivers to find the transmitter automatically on the same network. (Network configuration may be required for managed network switch.)
      • Support for Point-to-Many or Many-to-Many connections requires a managed Gigabit network switch with IGMP support and Jumbo frame support.
      • Manage transmitter/receiver connections and video wall configuration with web interface or network switch that supports VLAN.
      • Each VLAN acts as a separate HDMI Over IP Channel on the network.
      • When using multiple remote units, there are two USB control modes - Exclusive Mode and Sharing Mode.
      • USB Exclusive Mode: Only one remote unit can have USB control over the source computer at any time.
      • USB Sharing Mode: Multiple remote units share the control of the source computer.
      • Up to 5 USB devices will be recognized by the computer.
      • Customizable EDID table on local unit.
      • Supports the DDC2B protocol.
      • Easily expandable – add receivers as you add control stations.
      • Integrated mounting brackets for easy surface/wall mounting.

TECHNICAL

Local Unit

        • Compatible with a dual-head USB computer (PC, SUN and MAC) with Ultra-HD HDMI output.
        • Multiplatform support: Windows 2000/XP/Vista/7/8/10, Windows Server 2000/2003/2008/2012/2016/2019, Solaris, Linux, FreeBSD, and MAC OS 9/10.
        • Two female HDMI connectors for source.
        • Two female HDMI connectors for displays.
        • One female USB Type B connector.
        • Two female 3.5mm stereo jacks for audio out and mic in.
        • Speaker only works when in a point-to-point connection.
        • Two female RJ45 ports for sending/receiving high definition video/audio and USB signals.

    Remote Unit

              • Two female HDMI connectors.
              • Four female USB Type A connectors for keyboard, mouse, flashdrive, HDD, or touchscreen display.
              • Two USB 2.0 and two USB 1.1
              • Two female 3.5mm stereo jacks for audio out and mic in.
              • Microphone only works when in a point-to-point connection.
              • Two female RJ45 ports for sending/receiving high definition video/audio and USB signals.
              • Supported video resolutions:
              • Ultra-HD 4Kx2K resolutions (3840x2160 @ 30Hz)
              • 2K Cinema (2048x1080 @ 60Hz)
              • HDTV resolutions to 1080p
              • Up to 1920x1200 (WUXGA)
              • Supports embedded digital audio through HDMI compatible TVs or audio receivers.

          Power

          Local and remote unit:

            Input: 100 to 240 VAC at 50 or 60 Hz via AC adapter (included.)

            Output: 12 VDC, 5A


            Power consumption:

              Local unit: 13.2W

              Remote unit: 8.4W

              Cables

                      • Cables included with local unit:
                      • Two 6.56 ft (2 m) male to male HDMI cable.
                      • One 6 ft (1.8 m) male USB Type A to male USB Type B cable.
                      • One 5 ft (1.5 m) male to male 3.5mm stereo audio cable.
                      • Use HD-xx-MM HDMI cables to connect an HDMI source or display up to 20 feet (not included).
                      • Use HD-ACT-xx-MM 4K HDMI Active Cables to connect an HDMI source or display up to 100 feet (not included).
                      • Use DP-HD-xx-MM cables to connect a DisplayPort source (not included).
                      • Use DVI-HD-xx-MM cables to connect a DVI source or display (not included).
                      • Does not support 4Kx2K resolutions.
                      • Use CAT6/6a/7 straight through cable with TIA/EIA-568B wiring terminated with standard RJ45 connectors (not included).
                  Max Distance
                        • 492 feet in a Point-to-Point connection.
                        • 984 feet in a Point-to-Point, Point-to-Many, or Many-to-Many connection via a managed Gigabit network switch.
                        • The max length between most switches and the local/remote unit is 492 feet.
                        • The switch itself will determine the maximum distance.

                    Dimensions

                    Local and remote unit:

                      WxDxH (in): 6.30x4.33x1.99 (160x110x51 mm).

                      Environmental

                      Operating temperature: 32 to 122°F (0 to 50°C).

                      Storage temperature: -4 to 185°F (-20 to 85°C).

                      Operating/storage relative humidity: 0 to 80% non-condensing RH.

                      Regulatory Approval

                      CE, FCC, RoHS

                      TAA compliant

                      Warranty

                      2 Years



                      HD-3-MM 4K@60Hz, 1080p@120Hz (Length- 3 feet)
                      HD-6-MM 4K@60Hz, 1080p@120Hz (Length- 6 feet)
                      HD-10-MM 4K@60Hz, 1080p@120Hz (Length- 10 feet)
                      HD-15-MM 4K@60Hz, 1080p@120Hz (Length- 15 feet)
                      HD-25-MM 1080p@60Hz (Length- 25 feet)
                      HD-30-MM 1080p@60Hz (Length- 30 feet)
                      HD-50-MM 1080p@60Hz (Length- 50 feet)
                      HD-ACT-20-MM 4K@60Hz (Length- 20 feet)
                      HD-ACT-25-MM 4K@60Hz (Length- 25 feet)
                      HD-ACT-30-MM 4K@60Hz (Length- 30 feet )
                      HD-ACT-40-MM 4K@60Hz (Length- 40 feet)
                      HD-ACT-50-MM 4K@60Hz (Length- 50 feet)
                      HD-ACT-60-MM 4K@60Hz (Length-60 feet)
                      HD-ACT-75-MM 4K@30Hz (Length- 75 feet)
                      HD-ACT-100-MM 4K@30Hz (Length- 100 feet)
                      DVI-HD-1M-MM 1 meter
                      DVI-HD-2M-MM 2 meter
                      DVI-HD-3M-MM 3 meter
                      DVI-HD-5M-MM 5 meters
                      USB2-AB-0-5M-5T 0.5 meters (1.64 ft)
                      USB2-AB-3-5T 3 feet
                      USB2-AB-6-5T 6 feet
                      USB2-AB-10-5T 10 feet
                      USB2-AB-5M-5T 5 meters (16.4 ft)
                      ST-IPUSB4K-L-VWDH Local
                      ST-IPUSB4K-R-VWDH Remote
                      DP-HD-3-MM 4K@30Hz (Length- 3 feet)
                      DP-HD-6-MM 4K@30Hz (Length- 6 feet)
                      DP-HD-10-MM 4K@30Hz (Length- 10 feet)
                      DP-HD-15-MM 4K@30Hz (Length- 15 feet)
