TECHNICAL

VIDEO
Input	(1) HDMI (Type A female connector)
Output	(2) HDMI (Type A female connector); (1) TOSLINK, Spdif audio output; (1) 3.5mm jacket, L/R audio output HDMI HDMI 2.0/HDCP 2.2
Input resolution support	640 x 480@60Hz, 800x600@60Hz, 1024x768@ 60Hz, 1280x768@60 Hz, 1280x800@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1440x900@60Hz, 1600x900@60Hz
Output resolution support (bypass)	640 x 480@60Hz, 800x600@60Hz, 1024x768@ 60Hz, 1280x768@60 Hz, 1280x800@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1440x900@60Hz, 1600x900@60Hz
Output resolution support (scaling)	1920x1080@60Hz, 3840x2160@30Hz, 3840x2160@60Hz, 1280x720@60Hz, 1024x768@60Hz, 1366x768@60Hz, 1280x1024@60Hz, 1920x1200@60Hz, 1280x1024@60Hz/DVI, 1920x1080@60Hz/DVI
Input Video Level	0.5~1.2 Vp-p
Input DDC Signal	5 Vp-p
Maximum Data Rate	18 Gbps
Max Pixel Clock	600 MHz
OTHER
Power Supply	100-240 VAC/ 5VDC @ 3A/15W
Dimensions	5.63” W x 3.27” H x 1.02” D
Weight	0.8 lbs
Approvals	CE, FCC, RoHS Compliant
Operating Temperature	+32 to +104°F (0 to +40°C)
Storage Temperature	-4 to 140°F (-20 to +60°C)
Humidity	Up to 80% (No Condensation)
Support Warranty	1-year
