TECHNICAL

• “VT604” has a Linux OS running an 300 MHz ARM CPU. It is TCP / IP compliant and runs lighttpd web server including HTTPS (SSL), SMTP, DHCP, SNMP, FTP, Syslog, Radius. Web interface is mobile ready and runs on HTML5.

Multilanguage interface

• Web interface is has a multilanguage GUI and can be easily customized at request.

SNMP

• All SNMP functions including SNMP v.1, v.2c, v.3 are supported.
•  Also supports CAN bus commands, easy to configure CAN data to SNMP gateway.
• “VT604” has a Built-in Watchdog timer with NTP synchronisation.
• SNMP Get function supported.

CAN bus connection

• Up to 8 CAN devices can be connected to VT604. When plugged in, user needs to configure CAN units, and save configuration, then after reboot or energy lost, the system automatically reconfigures sensors. Using such CAN bus with max length 300 m, it is possible to connect up to 30 different sensor elements to a single monitoring unit.

 5-level sensor thresholds

• Sensors with 5-level thresholds allows direct connection to the SCADA system. The thresholds are usually: very low, low, normal, warning and alarm. Sensor levels can be inverted.

Processor	ARM926EJ 300 MHz
OS	Linux 3.10.101
ROM	512 Mbit NAND Flash
RAM	64 Mb
Operating temperature	0 to 60 °C
Storage temperature	–25 to 85 °C
Operating humidity	0 to 90 %, non-condensing
Storage humidity	0 to 95 %, non-condensing
Ethernet	10/100 Mbit port
Built-in clock with time synchronization
RADIUS access with Login
Device Management	Web, SNMP, manually via SMS
Built-in watchdog timer
Alert types	FTP, Syslog, SMTP or SNMP, SMS (GSM modem is ordered separately)
Network protocols	DHCP, HTTP, HTTPS, SNMP, SMTP, SSL, FTP,  Syslog, CAN, Get SNMP, TLS
